Moritex ML-M1218UR 12mm 2/3" 5MP Machine Vision Lens
Need help choosing the right configuration? Call 1-844-288-5143 — we configure systems every day.
Delivery Time
In-stock items will ship same day if order is placed by 12 pm EST.
Cognex12mm 2/3" 5MP Machine Vision Lens
The Moritex ML-M1218UR is a high-resolution 12mm fixed focal length C-mount lens designed for 2/3" 5MP sensors with 2.2μm pixel size. Delivering up to 200 lp/mm resolving power, this lens is optimized for modern Sony Pregius sensors such as IMX250 and IMX264. Rugged construction and broadband Vis/NIR AR coating ensure stable, high-contrast imaging in demanding industrial environments.
Key Features
• 12mm focal length optimized for 2/3" sensors
• Supports 5MP resolution (2.2μm pixel size)
• 200 lp/mm resolving power
• Vis/NIR AR coating (400–1000nm)
• Rugged, vibration-resistant construction
• Locking focus and iris controls
• Compact design for system integration
Typical Applications
• Machine vision inspection
• Semiconductor and PCB inspectionEmpire Optics
• Metrology and dimensional measurement
• Robotics and automation systems
• Barcode and label verification
• Surface defect detection
Technical Specifications
Manufacturer: Moritex
Model: ML-M1218UR
Focal Length: 12mm
Max Aperture: F1.8
Sensor Format: 2/3" (11mm image circle)
Resolution: 5MP / 200 lp/mm
Mount: C-Mount (17.526mm flange back)
Minimum Object Distance: 152mm
Filter Thread: M25.5 × 0.5
Dimensions: 29.5 × 40 mm
Weight: 60g
Distortion: -1.2%
Coating: Broadband Vis/NIR AR (400–1000nm)
Compatibility
Optimized for Sony IMX250, IMX264, and similar 5MP sensors. Ideal for use in high-resolution industrial imaging systems requiring stable, repeatable performance.
What’s Included & Ordering Notes
• Moritex ML-M1218UR Lens
• Protective caps
These lenses are typically built to order. Lead times vary depending on availability. Contact us for current lead time and application support.
Why Buy from Empire Optics?
• Fast, expert support (typically under 1 hour)
• Application guidance to ensure correct lens selection
• Authorized supplier of Moritex machine vision optics
• Trusted by engineers, integrators, and manufacturers
Other ML-M-UR Series Lenses
6mm • 8mm • 12mm (this model) • 16mm • 25mm • 35mm • 50mm
