Moritex ML-MC3518XR 35mm 1.1" 20MP Machine Vision Lens

35mm 1.1" 20MP Machine Vision Lens

The Moritex ML-MC3518XR is a high-resolution 35mm fixed focal length C-mount lens designed for 1.1" sensors and modern 20MP machine vision systems. Optimized for ~2.2µm pixel size sensors, this lens delivers exceptional image clarity, low distortion, and consistent performance for precision inspection and metrology applications requiring tighter fields of view.

Key Features

• 35mm focal length for narrow field of view and increased magnification

• Designed for 1.1" sensors (17.6mm image circle)

• Optimized for ~2.2µm pixel size (Sony Pregius S class sensors)

• Supports high-resolution 20MP imaging

• High resolving power for precision inspection

• Broadband Vis/NIR AR coating (400–1000nm)

• Rugged, vibration-resistant construction

• Manual focus and iris with locking screws

Typical Applications

• Semiconductor inspection and metrology

• Electronics and PCB inspection

• Precision measurement systems

• Robotics and automation

• Surface defect detection

• Applications requiring longer working distances

Technical Specifications

Manufacturer: Moritex

Model: ML-MC3518XR

Full Part Number: ML-MC3518XR-18C

Focal Length: 35mm

Max Aperture: F1.8

Sensor Format: 1.1" (17.6mm image circle)

Resolution: 20MP / optimized for ~2.2µm pixels

Mount: C-Mount

Filter Thread: M30.5 × 0.5

Coating: Broadband Vis/NIR AR (400–1000nm)

Compatibility

Optimized for Sony Pregius S sensors and other high-resolution 1.1" machine vision cameras. Ideal for applications requiring high magnification and precise detail capture.

What’s Included & Ordering Notes

• Moritex ML-MC3518XR Lens

• Protective caps


These systems are built to order. Contact us for current availability and lead times.

Why Buy from Empire Optics?

• Fast, expert support (typically under one hour)

• Application guidance to ensure correct lens selection

• Authorized Moritex / Cognex supplier

• Trusted by engineers, integrators, and manufacturers
