Moritex ML-MC9028XR 90mm 1.1" 20MP Machine Vision Lens

90mm 1.1" 20MP Machine Vision Lens

The Moritex ML-MC9028XR is a high-resolution 90mm fixed focal length C-mount lens designed for 1.1" sensors and modern 20MP machine vision systems. Engineered for maximum working distance and high magnification, this lens delivers outstanding image clarity, low distortion, and precise detail capture for demanding inspection, metrology, and automation applications.

Key Features

• 90mm focal length for maximum working distance

• Extremely narrow field of view for high magnification inspection

• Designed for 1.1" sensors (17.6mm image circle)

• Optimized for ~2.2µm pixel size sensors

• Supports high-resolution 20MP imaging

• High resolving power across the entire field

• Broadband Vis/NIR AR coating (400–1000nm)

• Rugged industrial construction with locking screws

Typical Applications

• Semiconductor inspection and metrology

• Electronics and PCB inspection

• Precision measurement systems

• Robotics and automation

• Long-distance inspection setups

• High-magnification defect detection

Technical Specifications

Manufacturer: Moritex

Model: ML-MC9028XR

Full Part Number: ML-MC9028XR-18C

Focal Length: 90mm

Max Aperture: F2.8

Sensor Format: 1.1" (17.6mm image circle)

Resolution: 20MP / optimized for ~2.2µm pixels

Mount: C-Mount

Filter Thread: M30.5 × 0.5

Coating: Broadband Vis/NIR AR (400–1000nm)

Compatibility

Optimized for Sony Pregius S sensors and other high-resolution 1.1" machine vision cameras requiring maximum working distance and extreme detail capture.

What’s Included & Ordering Notes

• Moritex ML-MC9028XR Lens

• Protective caps


These systems are built to order. Contact us for current availability and lead times.

Why Buy from Empire Optics?

• Fast, expert support (typically under one hour)

• Application guidance to ensure correct lens selection

• Authorized Moritex / Cognex supplier

• Trusted by engineers, integrators, and manufacturers
