Moritex ML-MC5020XR 50mm 1.1" 20MP Machine Vision Lens

50mm 1.1" 20MP Machine Vision Lens

The Moritex ML-MC5020XR is a high-resolution 50mm fixed focal length C-mount lens designed for 1.1" sensors and modern 20MP machine vision systems. Ideal for applications requiring longer working distances and tighter fields of view, this lens delivers excellent image clarity, low distortion, and high resolving power for demanding inspection and metrology environments.

Key Features

• 50mm focal length for long working distance applications

• Narrow field of view for detailed inspection

• Designed for 1.1" sensors (17.6mm image circle)

• Optimized for ~2.2µm pixel size sensors

• Supports high-resolution 20MP imaging

• High resolving power across the full field

• Broadband Vis/NIR AR coating (400–1000nm)

• Rugged industrial construction with locking screws

Typical Applications

• Semiconductor inspection and metrology

• Electronics and PCB inspection

• Precision measurement systems

• Robotics and automation

• Surface inspection at longer working distances

• Inline inspection systems

Technical Specifications

Manufacturer: Moritex

Model: ML-MC5020XR

Full Part Number: ML-MC5020XR-18C

Focal Length: 50mm

Max Aperture: F2.0

Sensor Format: 1.1" (17.6mm image circle)

Resolution: 20MP / optimized for ~2.2µm pixels

Mount: C-Mount

Filter Thread: M30.5 × 0.5

Coating: Broadband Vis/NIR AR (400–1000nm)

Compatibility

Optimized for Sony Pregius S sensors and other high-resolution 1.1" machine vision cameras requiring increased working distance and precise image detail.

What’s Included & Ordering Notes

• Moritex ML-MC5020XR Lens

• Protective caps


These systems are built to order. Contact us for current availability and lead times.
