Moritex ML-MC7528XR 75mm 1.1" 20MP Machine Vision Lens

75mm 1.1" 20MP Machine Vision Lens

The Moritex ML-MC7528XR is a high-resolution 75mm fixed focal length C-mount lens designed for 1.1" sensors and modern 20MP machine vision systems. Built for long working distance applications, this lens delivers exceptional image clarity, low distortion, and high resolving power for precision inspection, metrology, and automation where distance and detail both matter.

Key Features

• 75mm focal length for extended working distance

• Very narrow field of view for high magnification inspection

• Designed for 1.1" sensors (17.6mm image circle)

• Optimized for ~2.2µm pixel size sensors

• Supports high-resolution 20MP imaging

• High resolving power across the full field

• Broadband Vis/NIR AR coating (400–1000nm)

• Rugged industrial construction with locking screws

Typical Applications

• Semiconductor inspection and metrology

• Electronics and PCB inspection

• Precision measurement systems

• Robotics and automation

• Inspection where camera must be positioned far from target

• Inline and high-speed inspection systems

Technical Specifications

Manufacturer: Moritex

Model: ML-MC7528XR

Full Part Number: ML-MC7528XR-18C

Focal Length: 75mm

Max Aperture: F2.8

Sensor Format: 1.1" (17.6mm image circle)

Resolution: 20MP / optimized for ~2.2µm pixels

Mount: C-Mount

Filter Thread: M30.5 × 0.5

Coating: Broadband Vis/NIR AR (400–1000nm)

Compatibility

Optimized for Sony Pregius S sensors and other high-resolution 1.1" machine vision cameras requiring long working distances and high detail capture.

What’s Included & Ordering Notes

• Moritex ML-MC7528XR Lens

• Protective caps


These systems are built to order. Contact us for current availability and lead times.
